NOIL1SM0300A
PIN LIST
Table 14. PINLIST
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Name
GND ADC
DATA<5>
DATA<6>
DATA<7>
DATA<8>
DATA<9>
GND D
V DDD
GND ADC
V ADC
GND A
V DDA
ADC_BIAS
BIAS4
BIAS3
BIAS2
BIAS1
VPIX
SPI_ENABLE
SPI_CLK
SPI_DATA
VMEM_H
GND_DRIVERS
VRESET_1
VRESET_2
VRESET_3
PRECHARGE_BIAS
LINE_VALID
FRAME_VALID
INT_TIME_3
INT_TIME_2
INT_TIME_1
Type
Ground
Output
Output
Output
Output
Output
Ground
Supply
Ground
Supply
Ground
Supply
Biasing
Biasing
Biasing
Biasing
Biasing
Supply
Digital input
Digital input
Digital I/O
Supply
Ground
Supply
Supply
Supply
Bias
Digital output
Digital output
Digital I/O
Digital I/O
Digital I/O
Description
Ground supply of the ADCs
Databit<5>
Databit<6>
Databit<7>
Databit<8>
Databit<9> (MSB)
Digital ground supply
Digital power supply (2.5V)
Ground supply of the ADCs
Power supply of the ADCs (2.5V)
Ground supply of analog readout circuitry
Power supply of analog readout circuitry (2.5V)
Biasing of ADCs. Connect with 10 k W to VADC and decouple with
100n to GND_ADC
Biasing of amplifier stage. Connect with 110 k W to VDDA and de-
couple with 100 nF to GNDA
Biasing of columns. Connect with 42 k W to VDDA and decouple with
100 nF to GNDA
Biasing of columns. Connect with 1.5 M W to VDDA and decouple with
100 nF to GNDA.
Biasing of imager core. Connect with 500 k W to VDDA and decouple
with 100 nF to GNDA
Power supply of pixel array (2.5V)
Enable of the SPI
Clock of the SPI. (Max. 20 MHz)
Data line of the SPI. Bidirectional pin
Supply of vmem_high of pixelarray (3.3V)
Ground of pixel array drivers
Reset supply voltage (typical 3.3V)
Dual slope reset supply voltage. Connect to other supply or ground
when dual slope reset is not used
Triple slope reset supply voltage. Connect to other supply or ground
when triple slope reset is not used
Connect with 68 k W to VPIX and decouple with 100 nF to
GND_DRIVERS
Indicates when valid data is at the outputs. Active high
Indicates when valid frame is readout
In master mode: Output to indicate the triple slope integration time. In
slave mode: Input to control the triple slope integration time
In master mode: Output to indicate the dual slope integration time. In
slave mode: Input to control the dual slope integration time
In master mode: Output to indicate the integration time
In slave mode: Input to control integration time
33
V DDD
Supply
Digital power supply (2.5V)
http://onsemi.com
23
